»Install
Installing Consul on ECS is a multi-part process:
-
Terraform: Your tasks must be specified in Terraform using
ecs_task_definition
and ecs_service resources.
-
Consul Server: You must deploy the Consul server onto the cluster using the
dev-server module.
-
Task IAM Role: Modify task IAM role to add
ecs:ListTasks and ecs:DescribeTasks permissions.
-
Task Module: You can then take your
ecs_task_definition resources and copy their configuration into a new mesh-task module
resource that will add the necessary containers to the task definition.
-
Routing: With your tasks as part of the mesh, you must specify their upstream
services and change the URLs the tasks are using so that they're making requests
through the service mesh.
-
Bind Address: Now that all communication is flowing through the service mesh,
you should change the address your application is listening on to
127.0.0.1
so that it only receives requests through the sidecar proxy.
NOTE: This page assumes you're familiar with ECS. See What is Amazon Elastic Container Service for more details.
»Terraform
Your tasks must first be specified in Terraform using ecs_task_definition
and ecs_service resources so that
they can later be converted to use the mesh-task module.
For example, your tasks should be defined with Terraform similar to the following:
resource "aws_ecs_task_definition" "my_task" {
family = "my_task"
requires_compatibilities = ["FARGATE"]
network_mode = "awsvpc"
cpu = 256
memory = 512
execution_role_arn = "arn:aws:iam::111111111111:role/execution-role"
task_role_arn = "arn:aws:iam::111111111111:role/task-role"
container_definitions = jsonencode(
[{
name = "example-client-app"
image = "docker.io/org/my_task:v0.0.1"
essential = true
portMappings = [
{
containerPort = 9090
hostPort = 9090
protocol = "tcp"
}
]
cpu = 0
mountPoints = []
volumesFrom = []
}]
)
}
resource "aws_ecs_service" "my_task" {
name = "my_task"
cluster = "arn:aws:ecs:us-east-1:111111111111:cluster/my-cluster"
task_definition = aws_ecs_task_definition.my_task.arn
desired_count = 1
network_configuration {
subnets = ["subnet-abc123"]
}
launch_type = "FARGATE"
}
resource "aws_ecs_task_definition" "my_task" { family = "my_task" requires_compatibilities = ["FARGATE"] network_mode = "awsvpc" cpu = 256 memory = 512 execution_role_arn = "arn:aws:iam::111111111111:role/execution-role" task_role_arn = "arn:aws:iam::111111111111:role/task-role" container_definitions = jsonencode( [{ name = "example-client-app" image = "docker.io/org/my_task:v0.0.1" essential = true portMappings = [ { containerPort = 9090 hostPort = 9090 protocol = "tcp" } ] cpu = 0 mountPoints = [] volumesFrom = [] }] )}
resource "aws_ecs_service" "my_task" { name = "my_task" cluster = "arn:aws:ecs:us-east-1:111111111111:cluster/my-cluster" task_definition = aws_ecs_task_definition.my_task.arn desired_count = 1 network_configuration { subnets = ["subnet-abc123"] } launch_type = "FARGATE"}
»Consul Server
With your tasks defined in Terraform, you're ready to run the Consul server
on ECS.
NOTE: This is a development-only Consul server. It has no persistent
storage and so will lose any data when it restarts. This should only be
used for test workloads. In the future, we will support Consul servers
running in HashiCorp Cloud Platform and on EC2 VMs for production workloads.
In order to deploy the Consul server, use the dev-server module:
module "dev_consul_server" {
source = "hashicorp/consul/aws-ecs//modules/dev-server"
version = "<latest version>"
ecs_cluster_arn = var.ecs_cluster_arn
subnet_ids = var.subnet_ids
lb_vpc_id = var.vpc_id
load_balancer_enabled = true
lb_subnets = var.lb_subnet_ids
lb_ingress_rule_cidr_blocks = var.lb_ingress_rule_cidr_blocks
log_configuration = {
logDriver = "awslogs"
options = {
awslogs-group = aws_cloudwatch_log_group.log_group.name
awslogs-region = var.region
awslogs-stream-prefix = "consul-server"
}
}
}
data "aws_security_group" "vpc_default" {
name = "default"
vpc_id = var.vpc_id
}
resource "aws_security_group_rule" "ingress_from_server_alb_to_ecs" {
type = "ingress"
from_port = 8500
to_port = 8500
protocol = "tcp"
source_security_group_id = module.dev_consul_server.lb_security_group_id
security_group_id = data.aws_security_group.vpc_default.id
}
output "consul_server_url" {
value = "http://${module.dev_consul_server.lb_dns_name}:8500"
}
module "dev_consul_server" { source = "hashicorp/consul/aws-ecs//modules/dev-server" version = "<latest version>"
ecs_cluster_arn = var.ecs_cluster_arn subnet_ids = var.subnet_ids lb_vpc_id = var.vpc_id load_balancer_enabled = true lb_subnets = var.lb_subnet_ids lb_ingress_rule_cidr_blocks = var.lb_ingress_rule_cidr_blocks log_configuration = { logDriver = "awslogs" options = { awslogs-group = aws_cloudwatch_log_group.log_group.name awslogs-region = var.region awslogs-stream-prefix = "consul-server" } }}
data "aws_security_group" "vpc_default" { name = "default" vpc_id = var.vpc_id}
resource "aws_security_group_rule" "ingress_from_server_alb_to_ecs" { type = "ingress" from_port = 8500 to_port = 8500 protocol = "tcp" source_security_group_id = module.dev_consul_server.lb_security_group_id security_group_id = data.aws_security_group.vpc_default.id}
output "consul_server_url" { value = "http://${module.dev_consul_server.lb_dns_name}:8500"}
NOTE: The documentation for all possible inputs can be found in the module reference
docs.
The example code above will create a Consul server ECS task and Application Load
Balancer for the Consul UI. You can then use the output consul_server_url as
the URL to the Consul server.
»Task IAM Role
Your tasks must have an IAM role that allows them to list and describe
other tasks. This is required in order for the tasks to find the IP
address of the Consul server.
The specific permissions needed are:
-
ecs:ListTasks on resource *.
-
ecs:DescribeTasks on all tasks in this account and region. You can either
use * for simplicity or scope it to the region and account, e.g. arn:aws:ecs:us-east-1:1111111111111:task/*. If
your account is configured to use the new, longer ECS task ARN format
then you can further scope ecs:DescribeTasks down to tasks in a specific cluster, e.g. arn:aws:ecs:us-east-1:1111111111111:task/MY_CLUSTER_NAME/*.
The IAM role's ARN will be passed into the mesh-task module in the next step
via the task_role_arn input.
NOTE: There are two IAM roles needed by ECS Tasks: Execution roles and
Task roles. Here we are referring to the Task role, not the Execution role.
The Execution role is used by ECS itself whereas the Task role defines the
permissions for the containers running in the task.
Terraform for creating the IAM role might look like:
data "aws_caller_identity" "this" {}
resource "aws_iam_role" "this_task" {
name = "this_task"
assume_role_policy = jsonencode({
Version = "2012-10-17"
Statement = [
{
Action = "sts:AssumeRole"
Effect = "Allow"
Sid = ""
Principal = {
Service = "ecs-tasks.amazonaws.com"
}
},
]
})
inline_policy {
name = "this_task"
policy = jsonencode({
Version = "2012-10-17"
Statement = [
{
Effect = "Allow"
Action = [
"ecs:ListTasks",
]
Resource = "*"
},
{
Effect = "Allow"
Action = [
"ecs:DescribeTasks"
]
Resource = [
"arn:aws:ecs:${var.region}:${data.aws_caller_identity.this.account_id}:task/*",
]
}
]
})
}
}
data "aws_caller_identity" "this" {}
resource "aws_iam_role" "this_task" { name = "this_task" assume_role_policy = jsonencode({ Version = "2012-10-17" Statement = [ { Action = "sts:AssumeRole" Effect = "Allow" Sid = "" Principal = { Service = "ecs-tasks.amazonaws.com" } }, ] })
inline_policy { name = "this_task" policy = jsonencode({ Version = "2012-10-17" Statement = [ { Effect = "Allow" Action = [ "ecs:ListTasks", ] Resource = "*" }, { Effect = "Allow" Action = [ "ecs:DescribeTasks" ] Resource = [ "arn:aws:ecs:${var.region}:${data.aws_caller_identity.this.account_id}:task/*", ] } ] }) }}
»Task Module
In order to add the necessary sidecar containers for your task to join the mesh,
you must use the mesh-task module.
The module will reference the same inputs as your old ECS task definition but it will
create a new version of the task definition with additional containers.
The mesh-task module is used as follows:
module "my_task" {
source = "hashicorp/consul/aws-ecs//modules/mesh-task"
version = "<latest version>"
family = "my_task"
execution_role_arn = "arn:aws:iam::111111111111:role/execution-role"
task_role_arn = "arn:aws:iam::111111111111:role/task-role"
container_definitions = [
{
name = "example-client-app"
image = "docker.io/org/my_task:v0.0.1"
essential = true
portMappings = [
{
containerPort = 9090
hostPort = 9090
protocol = "tcp"
}
]
cpu = 0
mountPoints = []
volumesFrom = []
}
]
port = "9090"
consul_server_service_name = module.dev_consul_server.ecs_service_name
}
module "my_task" { source = "hashicorp/consul/aws-ecs//modules/mesh-task" version = "<latest version>"
family = "my_task" execution_role_arn = "arn:aws:iam::111111111111:role/execution-role" task_role_arn = "arn:aws:iam::111111111111:role/task-role" container_definitions = [ { name = "example-client-app" image = "docker.io/org/my_task:v0.0.1" essential = true portMappings = [ { containerPort = 9090 hostPort = 9090 protocol = "tcp" } ] cpu = 0 mountPoints = [] volumesFrom = [] } ]
port = "9090" consul_server_service_name = module.dev_consul_server.ecs_service_name}
All possible inputs are documented on the module reference documentation
however there are some important inputs worth highlighting:
-
family is used as the task definition family
but it's also used as the name of the service that gets registered in Consul.
-
container_definitions accepts an array of container definitions.
These are your application containers and this should be set to the same value as what you
were passing into the container_definitions key in the aws_ecs_task_definition resource
without the jsonencode() function.
For example, if your original task definition looked like:
resource "aws_ecs_task_definition" "my_task" {
...
container_definitions = jsonencode(
[
{
name = "example-client-app"
image = "docker.io/org/my_task:v0.0.1"
essential = true
...
}
]
)
}
resource "aws_ecs_task_definition" "my_task" { ... container_definitions = jsonencode( [ { name = "example-client-app" image = "docker.io/org/my_task:v0.0.1" essential = true ... } ] )}
Then you would remove the jsonencode() function and use the rest of the value
as the input for the mesh-task module:
module "my_task" {
source = "hashicorp/consul/aws-ecs//modules/mesh-task"
version = "<latest version>"
...
container_definitions = [
{
name = "example-client-app"
image = "docker.io/org/my_task:v0.0.1"
essential = true
...
}
]
}
module "my_task" { source = "hashicorp/consul/aws-ecs//modules/mesh-task" version = "<latest version>"
... container_definitions = [ { name = "example-client-app" image = "docker.io/org/my_task:v0.0.1" essential = true ... } ]}
-
port is the port that your application listens on. This should be set to a
string, not an integer, i.e. port = "9090", not port = 9090.
-
consul_server_service_name should be set to the name of the ECS service for
the Consul dev server. This is an output of the dev-server module so it
can be referenced, e.g. consul_server_service_name = module.dev_consul_server.ecs_service_name.
The mesh-task module will create a new version of your task definition with the
necessary sidecar containers added so you can delete your existing aws_ecs_task_definition
resource.
Your aws_ecs_service resource can remain unchanged except for the task_definition
input which should reference the new module's output of the task definition's ARN:
resource "aws_ecs_service" "my_task" {
...
task_definition = module.my_task.task_definition_arn
}
resource "aws_ecs_service" "my_task" { ... task_definition = module.my_task.task_definition_arn}
NOTE: If your tasks run in a public subnet, they must have assign_public_ip = true
in their network_configuration block so that ECS can pull the Docker images.
After running terraform apply, you should see your tasks registered in
the Consul UI.
»Routing
Now that your tasks are registered in the mesh, you're able to use the service
mesh to route between them.
In order to make calls through the service mesh, you must configure the sidecar
proxy to listen on a different port for each upstream service your application
needs to call. You then must modify your application to make requests to the sidecar
proxy on that port.
For example, say my application web wants to make calls to my other application
backend.
First, I must configure the mesh-task module's upstreams:
module "web" {
family = "web"
upstreams = [
{
destination_name = "backend"
local_bind_port = 8080
}
]
}
module "web" { family = "web" upstreams = [ { destination_name = "backend" local_bind_port = 8080 } ]}
I set the destination_name to the name of the upstream service (in this case backend),
and I set local_bind_port to an unused port. This is the port that the sidecar proxy
will listen on and any requests to this port will be forwarded over to the destination_name.
This does not have to be the port that backend is listening on because the service mesh
will handle routing the request to the right port.
If you have multiple upstream services they'll each need to be listed here.
Next, I must configure my application to make requests to localhost:8080 when
it wants to call the backend service.
For example, if my service allows configuring the URL for backend via the
BACKEND_URL environment variable, I would set:
module "web" {
family = "web"
upstreams = [
{
destination_name = "backend"
local_bind_port = 8080
}
]
container_definitions = [
{
name = "web"
environment = [
{
name = "BACKEND_URL"
value = "http://localhost:8080"
}
]
...
}
]
...
}
module "web" { family = "web" upstreams = [ { destination_name = "backend" local_bind_port = 8080 } ] container_definitions = [ { name = "web" environment = [ { name = "BACKEND_URL" value = "http://localhost:8080" } ] ... } ] ...}
»Bind Address
To ensure that your application only receives traffic through the service mesh,
you must change the address that your application is listening on to only the loopback address
(also known as localhost, lo and 127.0.0.1)
so that only the sidecar proxy running in the same task can make requests to it.
If your application is listening on all interfaces, e.g. 0.0.0.0, then other
applications can call it directly, bypassing its sidecar proxy.
Changing the listening address is specific to the language and framework you're
using in your application. Regardless of which language/framework you're using,
it's a good practice to make the address configurable via environment variable.
For example in Go, you would use:
s := &http.Server{
Addr: "127.0.0.1:8080",
...
}
log.Fatal(s.ListenAndServe())
s := &http.Server{ Addr: "127.0.0.1:8080", ...}log.Fatal(s.ListenAndServe())
In Django you'd use:
python manage.py runserver "127.0.0.1:8080"
python manage.py runserver "127.0.0.1:8080"
»Next Steps
- Now that your applications are running in the service mesh, read about
other Service Mesh features.
- View the Architecture documentation to understand
what's going on under the hood.
